Overview
High-performance ECG trunk cables designed for stable, low-noise signal transmission across multi-parameter patient monitoring systems. Compatible with leading brands including Philips, GE, Mindray, and Nihon Kohden. Ideal for ICU, bedside, and long-term ECG monitoring applications.
Product Overview
What is an ECG Trunk Cable?
An ECG trunk cable (also known as ECG patient cable) is a multi-channel main cable used to connect ECG lead wires to patient monitoring systems. It serves as the primary signal transmission link, ensuring accurate and stable electrocardiogram (ECG) data delivery from the patient to the monitor.
Equipment Compatibility
Our ECG trunk cables are designed for seamless integration with:
•Patient monitoring systems
•Bedside ECG monitors
•Holter ECG recorders
•Central monitoring systems
Main Functions
•Multi-channel ECG signal transmission (3-lead / 5-lead / 12-lead)
•Stable and low-noise signal output
•Reliable connection between ECG lead wires and monitors
•Support for continuous and long-term patient monitoring
Application Scenarios
ECG trunk cables are widely used in:
•Hospitals and clinical environments
•Intensive Care Units (ICU)
•Operating rooms
•Emergency departments
•Long-term monitoring and telemetry
Specifications
| Parameter | Specification |
| Number of Leads | 3-lead / 5-lead / 10-lead / 12-lead |
| Conductor Material | Tinned copper / Silver-plated copper |
| Wire Gauge | AWG 26–28 |
| Insulation Resistance | ≥ 100 MΩ |
| Shielding | Braided shield / Foil + braid |
| Jacket Material | Medical-grade TPU / PVC |
| Outer Diameter | Customized based on lead count |
| Signal Stability | Designed for low attenuation and long-distance transmission |
| Pull Force Resistance | Meets medical cable mechanical standards |
| Compatibility | Philips / GE / Mindray / Nihon Kohden / Comen |
Key Features
•Multi-channel design for 3-lead, 5-lead, 10-lead, and 12-lead ECG systems
•Advanced low-noise cable structure for accurate waveform transmission
•High-performance EMI shielding to reduce interference
•Reinforced strain relief design for durability
•Designed for frequent bending and intensive clinical use
•OEM customizable connectors and pin configurations
•Compatible with major patient monitor brands
Technical Advantages
1.Low-Noise Conductor Coating Technology
ECG signals are extremely low in amplitude and highly sensitive to interference. Our cables integrate advanced conductor-level technologies:
•Graphite or carbon-based conductive coatings
•Semi-conductive layers on conductors
•Noise-damping materials
Benefits:
•Reduces triboelectric noise caused by cable movement
•Minimizes signal distortion during patient motion
•Improves ECG waveform clarity
2.Optimized Multi-Core Structure
To ensure signal integrity across multiple channels:
•Optimized conductor layout
•Balanced impedance design
•Reduced cross-talk between channels
This ensures stable ECG signal transmission even in high-density configurations.
3.Multi-Layer Shielding Design
Shielding options based on application requirements:
•Foil shielding (high-frequency noise protection)
•Braided shielding (mechanical durability)
•Combined shielding (maximum EMI protection)
4.Built for Clinical Durability
Designed for demanding healthcare environments:
•Reinforced strain relief
•High flex-life materials
•Stable long-term electrical performance
Ideal for ICU, bedside monitoring, and continuous use.
Compatible Brands
Our ECG trunk cables are compatible with:
•Philips patient monitors
•GE Healthcare monitoring systems
•Mindray patient monitors
•Nihon Kohden ECG systems
•Comen monitoring devices
✅ Custom connectors available for specific models and requirements
Applications
ECG trunk cables are used in:
•Hospital patient monitoring systems
•Bedside ECG monitoring devices
•Holter ECG recording systems
•Central monitoring stations
Typical Use Case
In ICU environments, ECG trunk cables act as the main connection between patient lead wires and monitors, ensuring stable multi-channel signal transmission during continuous monitoring.
Quality & Compliance
Our ECG trunk cables are manufactured under strict medical-grade standards:
•ISO 13485 certified manufacturing system
•Designed according to IEC 60601-1 safety standards
•EMC compliance (IEC 60601-1-2)
•RoHS & REACH compliant materials
•Full production traceability
Why Choose Us
•Professional manufacturer of medical cable assemblies
•Strong OEM / ODM customization capability
•Advanced low-noise cable design (beyond standard shielding)
•Flexible production (low MOQ supported)
•Fast prototyping (2–3 weeks)
•Reliable quality for long-term hospital and OEM supply
